3″ D/L 80 PP Bolted

Home 9 Tabla Air Diaphragm Pumps 9 3″ D/L 80 PP Bolted
Tabla Air Diaphragm Pumps
Tabla Pumps 3" D/L 80 PP Bolted

Specifications

Max Flow Rate 900 Lpm (238gpm)
Port Size Inlet: 76.20 mm (3)
Discharge: 76.20 mm (3)
Air Inlet: 12.70 mm (1/2)
Air Exhaust: 19.05 mm (3/4)
Suction Lift Dry: 6.09 m (20)
Wet: 7.62 m (25)
Teflon Dry: 3.05 m (10)
Wet: 6.09 m (20)
Max. Particle Size (Dia) 19.10 mm (0.750)

All models available in NPT and BSP threads for liquid and air side connections

Capacity External Pump

Download Manual
